1144758 Avata 2 LED Propeller Gurad Bumper Installation

Installation Steps:

1. Identify Left and Right Parts: Take the LED propeller guards labeled "L" and "R" from the packaging, corresponding to the left and right sides.
2. Install Left Guard: Attach the LED propeller guard labeled "L" to the left side of the Avata 2, following the diagram to secure it.
3. Install Right Guard: Attach the LED propeller guard labeled "R" to the right side of the Avata 2, ensuring it clicks into place securely.
4. Attach Battery Compartment: Clip the propeller guard's battery compartment into the battery slot of the Avata 2.
5. Connect the Cables: Connect the cables from the left and right propeller guards to the corresponding ports on the battery compartment.
6. Power On: Press and hold the power button for 3 seconds to turn on the device. Single-click the button to select your preferred light mode.
7. Complete Installation: Ensure all components are securely fastened, and you're ready to enjoy your flight.

Precautions:

• Charge Before First Use: Before first use or after long-term storage, fully charge the product. It typically takes 3-5 charge and discharge cycles to restore the battery to full capacity.
• Use Certified Chargers: Use only approved chargers and accessories. Unapproved devices may damage the product.
• Charging and Storage Conditions: Avoid moisture; charge and store the product in a well-ventilated, dry location. Do not operate in areas with strong magnetic fields or restricted zones.
• Secure Components: After installation, ensure all components are firmly secured to prevent any loosening during flight.
• No Unauthorized Modifications or Repairs: Unauthorized modifications or repairs may cause malfunction and void the warranty. In case of issues, contact an authorized service center for professional repairs.
